Performance to rule your game

GAME. STREAM. ADVANCE.

Experience incredible performance, visuals, and efficiency when gaming and streaming with the AMD Radeon™ RX 7700 XT graphics cards, powered by the  AMD RDNA™ 3 architecture. Immerse yourself in next-generation desktop experiences on some of the most advanced high refresh rate displays with GB of GDDR6 memory, new frame generation technologies, advanced raytracing, AI accelerators, AV1 encoding, and support for the latest DisplayPort™ 2.1 technology. The Radeon™ RX 7700 XT   delivers an incredible high refresh 1440p gaming & streaming experience, with additional video memory to step into 4K.

Game Clock, Up To 2171 MHz

Boost Clock, Up To 2544 MHz

GDDR6 Memory Size 12 GB

Memory Clock Speed 18 GBPS

Manufacturer

‍Manufacturer: XFX
Model Number: RX 77TSWFTFP
Product Name: AMD Radeon™ RX 7700 XT
Product Description: XFX SPEEDSTER QICK319 RADEON RX 7700 XT BLACK Gaming Graphics Card with 12GB GDDR6 HDMI 3xDP, AMD RDNA™ 3
Product Name: AMD Radeon™ RX 7700 XT
Product Description: XFX SPEEDSTER QICK319 RADEON RX 7700 XT BLACK Gaming Graphics Card with 12GB GDDR6 HDMI 3xDP, AMD RDNA™ 3
Short Description : XFX SPEEDSTER QICK319 RADEON RX 7700 XT BLACK
Launch Date: June 2024
UPC Number: 840191502453

Specifications

‍Bus Type: PCI-E 4.0

‍
Primary Clock Speeds:
Base Clock Up To:  1425 MHz
Game Clock Up To: 2171 MHz
Boost Clock Up to: 2544 MHz

Stream Processors:  3456
Compute Units: 54
Memory Bus: 192bit
Memory Clock: 18 Gbps
Memory Size: 12 GB
Memory Bandwidth: Up to 432 GB/s
Effective Memory Bandwidth: Up to 1995 GB/s
Memory Type: GDDR6
Card Profile:  2.5 slot
Thermal Solution: 2 Fan

*"Game Clock" is the expected GPU clock when running in typical gaming applications, set to typical TGP (Total Graphics Power). Actual individual game clock results may vary.

**"Boost Clock" is the maximum frequency achievable on the GPU running a bursty workload. Boost clock achievability, frequency, and sustainability will vary based on several factors, including but not limited to: thermal conditions and variation in applications and workloads.

Outputs

‍DisplayPort 2.1: 3x ‍
HDMI™ 2.1: 1x

Requirements

‍External Power: 2x PCI-E 8 pin connections
Minimum Power Supply Requirement: 700 watt

‍

Certifications

RoHS

Package Contents

Warranty card - QR Code Insert: 1x

Estimated Dimensions & Weights

‍Card Dimension (cm) 28.3 x 12.5 x 5.2
Card Dimension (inch) 11.1 x 54.9 x  2
Master Carton Dimensions (cm) 46 x 39.5 x 47.5
Master Carton Dimensions (inch) 18.11 x 15.55 x 18.7
Master Carton Weight (Kg) ~11.58
Master Carton Weight (lb) ~25.53
Package Dimensions (cm) 44.5x 23.5 x 12.5
Package Dimensions (inch) 17.51 x 9.25 x 4.92
Package Weight (Kg) ~1.7
Package Weight (lb) ~3.74
Units/Carton 8

Technologies

54 AMD RDNA™ 3 Compute Units(with RT+AI Accelerators)
AMD Infinity Cache™ technology
DisplayPort™ 2.1
AMD Radiance Display™ Engine
AMD Radeon™ Boost technology*
AMD Radeon™ Anti-Lag* technology*
16GB GDDR6 on 192-Bit Memory Bus
PCI® Express 4.0 ready
AMD FidelityFX™ technologies*
AMD FidelityFX™ Super Resolution technology*
Microsoft® DirectX® 12 Ultimate
Microsoft® DirectStorage
Vulkan® Optimized
AMD smart technologies*
AMD Software: Adrenalin Edition™ application
AMD Noise Suppression*
AMD Privacy View*
AMD Radeon™ Super Resolution technology*
AMD Link*
AMD Freesync™ technology*

Key Features

HDMI™ 4K Support
4K H264 Decode
4K H264 Encode
H265/HEVC Decode
H265/HEVC Encode
AV1 Decode
AV1 Encode
