Cooler Master MF360 Stage LCD Gaming PC Case Black - Features

The Cooler Master MasterFrame 360 STAGE LCD is a premium open-frame chassis designed to turn your PC into a true visual centerpiece. Built as a panoramic showcase, it combines high-end materials with an integrated front LCD display, allowing your build to function as both a powerful system and a dynamic display stage for creativity, content, and customization.

At the heart of the design is the built-in LCD screen, which brings your system to life with real-time visuals, animations, or system data. With multiple display modes and full customization support, the MasterFrame 360 STAGE LCD is ideal for modders, collectors, and enthusiasts looking to elevate their setup beyond traditional cases.

Integrated LCD Display

The front LCD panel supports two versatile modes:

• Extended Display Mode – Functions as a secondary monitor for applications, system stats, or live video content
• Custom Playback Mode – Features pre-installed animations, perfect for showcasing collectible figures or themed builds

You can also upload your own visuals via MicroSD card, supporting JPG and MP4 formats for fully personalized content.

Built for High-End Hardware

The open-frame layout offers exceptional hardware compatibility and flexibility:

• Supports ATX, Micro-ATX, Mini-ITX, and ATX BTF (Back-to-Front) motherboards
• Vertical GPU mounting with PCIe 5.0 riser cable included
• Accommodates graphics cards up to 430 mm
• Supports power supplies up to 210 mm
• Generous 110 mm rear cable clearance for clean, professional cable management

Extreme Cooling Potential

Designed for enthusiast-grade cooling and custom loops:

• Supports up to 12 × 120 mm fans or 6 × 200 mm fans
• Radiator support up to 360 mm (top or bottom)
• Fully compatible with advanced custom liquid-cooling configurations

Key Features

• Panoramic open-frame showcase design
• Integrated front LCD display with customizable content
• Vertical GPU support with PCIe 5.0 riser included
• Extensive fan and radiator compatibility
• Premium construction using steel, aluminum, and tempered glass
• Front I/O with USB 4.0 Gen 2x2 Type-C (20 Gbps)

Specifications

• Model: Cooler Master MasterFrame 360 STAGE LCD
• Type: Open-frame / showcase chassis with LCD display
• Color: Black
• Materials: Steel, aluminum, tempered glass
• Motherboard Support: ATX / Micro-ATX / Mini-ITX / ATX BTF
• GPU Support: Up to 430 mm (vertical mount)
• PSU Support: Up to 210 mm
• Fan Support:
  • Top: up to 6 × 120 mm or 3 × 200 mm
  • Bottom: up to 6 × 120 mm or 3 × 200 mm
• Radiator Support: Up to 360 mm (top or bottom)

Front I/O

• 1 × USB 4.0 Gen 2x2 Type-C (20 Gbps)
• 2 × USB 3.2 Gen 1 Type-A (5 Gbps)
• 1 × 3.5 mm combo audio jack

Included Accessories

• PCIe 5.0 riser cable
• Modular mounting brackets
• PSU screw and bracket kit
• User manual

The MasterFrame 360 STAGE LCD is more than a PC case—it’s a display platform built for creators, modders, and enthusiasts who want their hardware to be seen, admired, and fully expressed.
